J518c 5 Hole Hydraulic Split Sae J518 Code 62 Flanges Dimensions

Black metal split flange is commonly used world wide to connect larger sizes of hose and tubing (3/4” to 3”) in fluid power systems.
Carbon steel split flange come in two pressure classes. The standard series, Code 61, which goes to 3,000 psi and the high pressure series, Code 62, where all the sizes are rated at 6,000 psi.

Sae flange clamp Description
1. SAE J518 Types of fange clampes, split flange clamps and one-piece flange clamps and 2 bolt fange clamps.
2. Working pressure type, SAE code 61 fange and SAE code 62 fange;
3. Application of SAE flange clamps in hydraulic excavatorloader etc.

Split flange clamps Application

Sae j518 split flange clamps 3000psi Applications: Automobile,Engineering Machinery,Lathe,Agriculture Machine,Mining,Spurting the Oil Paint, Metallurgy petroleum, Construction, Chemicals,Textile, Ships, Ocean Military, Recreation, Electronics and so forth.

Flange clamps Advantage
The stainless steel split flange make it easy to assemble the connection in close quarters. They also make removal of the flange head component, such as a hose assembly, easy by loosening all four bolts and removing one clamp half.

About US

Topa is the professional hydraulic fitting and hose solution provider. We not only sell hydraulic fitting and hose, but also provide solutions to customers.

Our main products are hydraulic flange clamp, hydraulic fittings, hydraulic hose, adapters and related products.

In TOPA you will find exactly products you want. We are a one-stop manufacturer for all your hydraulic products needs!

Stainless steel flange clamps Package
1. sae j518c flanges use plastic film bag inside;
2. mounting flange clamp’ cartons with model, quantity, size mark;
3. sae split flange clamp’s use pallet packaging;
4. split flange exhaust clamp accepts customized pallet sizes;

FAQ

Flange clip Related Products

How to contact us?

For more information about the sae j518 hydraulic thread flange, please contact us.
