Basic Info
Model No.: 20441
Certification: ISO9001
Pressure: High Pressure
Work Temperature: High Temperature
Installation: Welded
Material: Carbon Steel
Type: Other, 20441 Parker Air Hose
Connection: Female Or Male
Head Code: Hexagon, Round & Forged
Shape: Male Connector, Female Connector, Hex Union, Elbow
Materials: Carbon Steel, Stainless Steel
Size: DN 6MM To 50MM
Standard: Metric
Color: Silver
Surface Treatment: Zinc Plated, Nickle Plating
Name: 20441 Parker Air Hose
Thread Type: Internal Thread
Additional Info
Packaging: carton and wooden case
Productivity: 500000 pcs per month
Brand: Topa
Transportation: Ocean,Land,Air,DHL/UPS/TNT
Place of Origin: China
Supply Ability: 500000 pcs per month
Certificate: Hydraulic Fittings ISO
HS Code: 73071900
Port: Ningbo,Shanghai,Tianjin
Product Description
Hydraulic Fiting allow designers to change flow direction, the elevation of lines or split flow. Crimping is the most common method for assembling hoses and Hydraulic Hose Fitting. Metric Hydraulic Fittings are made of many different materials including stainless steel, brass, plastic, Monel and more.
Product Description
Application
E
HOSE BORE
DIMENSIONS
PART NO.
THREAD E
DN
DASH
TUBE O.D.
C
S
H
20441-14-04
M14X1.5
6
04
8
2
19
27
20441-16-05
M16X1.5
8
05
10
2
22
28.2
20441-18-06
M18X1.5
10
06
12
2.5
24
29.2
20441-22-08
M22X1.5
12
08
15
2.5
27
33.2
20441-26-10
M26X1.5
16
10
18
2.5
32
35.9
20441-27-10
M27X1.5
16
10
18
2.5
32
35.9
20441-30-12
M30X2
20
12
22
4
36
41.7
20441-36-16
M36X2
25
16
28
4
41
42.8
hydraulic Hose Fittings is widely used in the hydraulic and fluid conveying ststem of machinery, oilfield, mine, building, transportation and other industries.
Company Information
Hose Connectors connect conductors such as hoses, pipes and tubes in a hydraulic system. Hose Pipe Fittings have a male and female component that join to form a connection. These Hydraulic Pipe Fittings help contain and direct the flow of hydraulic fluid in the conductor while preventing leaks and maintaining pressure. Different hoes end fittings allow designers to change flow direction, the elevation of lines or split flow. Crimping is the most common method for assembling hoses and industrial hose fittings. Gates Hydraulic Hose Fittings are made of many different materials including stainless steel, brass, plastic, Monel and more. Not always, but often fittings match the material of the conductor used in a system.
Our high pressure fittings products include a wide range of standard : Eaton standard, Parker standard, American standard , custom, and jump size fittings from 1/8″ to 2″ and so on. Virtually any straight or shape style fitting whether tube fitting, pipe fitting, or swivel fitting Adapter can be machined in NPT, JIC, ORFS, BSP, BSPT, BSPP, or S. A. E. thread forms and all are meet REACH and RoHS compliant in surface treatments.
Packaging&Shipping
Hose Pipe Connector Packing Details:
1.our metric tube fittings have threads cap, can protect the goods, ensure you can receive goods with all perfect threads.
2.each hydraulic swivel fitting will be covered by plastic cover.
3. then package by carton.
4. 48-52 small cartons Hydraulic Hose Ferrule Fittings are in a wooden pallet.
5. our package is perfect, protect fitting clash in transport.
6.Of course, we also allow to do customized package.
Inspection
Our QC procedure:
As we had more than 10 professional and technical personal, they ensure 100% products checking.
(1).Material checking: strictly control of material using, meet international requested standards;
(2).First inspection: Check first product in each procedure.
(3). semi-finished products inspection: in working process, workers check size as per drawing and check thread with thread gauge ;
(4). Production line test: Quality Inspector will inspect machines, lines and products at any time and any place.
(5). Finished product inspection: inspection department will test and check before products are plated zinc.
(6). After plate zinc: also need to check fitting size, crimp nut,quantity and finally check again, then packed and loaded.
Each our products will past through test strictly by our professional technical personal
Why Choose Us?
Why choose us?
1) Company strength:
Work shop: 50,000 square meter; Employees: 350; Production capacity monthly: 1,500,000 set of hydraulic fittings; OEM project: Meritor
2) Experience :
A company with professional team and more than 20 years experience in the production of wheel hydraulic fittings exporting to more than 90 countries.
3) Quality policy:
We strictly comply with quality management systems of ISO9001/TS16949. Quality Guarantee: 100% strict inspection on each order before shipment
4 )Service: Rapid , Effective , Professional , Kind
Advantages
I’m so glad to introduce our advantage to you
1.More competitive price than other suppliers.
2.Own 20 years experience.
3.Delivery on time.
4.High quality products and perfect after-sales service.
5.products inspect 100% using high accuracy tools to ensure that the minimum error.
FAQ
Q: Are you trading company or manufacturer ?
A: We are a manufacturer with our own trading company in Shijiazhuang.
Q: How long is your delivery time?
A: Generally it is 2-10 days if the goods are in stock. or it is 20-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge,freight charge is for your account. If you make order, we could return freight charge.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance , balance before shippment.
Q: Can you customize products for your customers?
A: Yes, Customized service is one of our core business.
Q:Will you do 100% inspection before Shipment?
A: Our QC will do 100% inspection and we will take the 100% claims if defective.
How To Contact Us?
Looking for ideal 20441 Parker Air Hose Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Carbon Steel Air Hose are quality guaranteed. We are China Origin Factory of Tractor Air Hose. If you have any question, please feel free to contact us.
Product Categories : Hydraulic Hose Fitting > Metric Hydraulic Fitting
